TB型提炭泵技術參數 Parameter of carbon-lifting pump
| 型號規格Model | 揚程Delivery lift | 流量Flow rate | 主軸轉速Turning speed of themain shaft | 排出管徑Diameter of dischargingpipe | 電動機型號Motor | 功率Power | 重量Weight | 備注Remarks |
| m | L/S | r/min | mm | kw | kg | |||
| TB－3 | 3 | 1.6 | 516 | 50 | Y100L1-4 | 2.2 | 630 | |
| TB－7 | 7 | 1.6 | 817 | 50 | Y112M-4 | 4 | 640 |
