JZ型鑿井絞車Scrarer ramp seriesJZ系列鑿井絞車主要用于煤礦及非金屬礦鑿井時懸吊設備的絞車。JZ scraper ramp series are winches mainly used to suspend equipment during the drilling of coal mines and nonmetallic mines.型號規格 Model鋼絲繩 Rope
JZ型鑿井絞車Scrarer ramp series
JZ系列鑿井絞車主要用于煤礦及非金屬礦鑿井時懸吊設備的絞車。
JZ scraper ramp series are winches mainly used to suspend equipment during the drilling of coal mines and nonmetallic mines.
| 型號規格 Model | 鋼絲繩 Rope | 鋼繩速度m/s | 容繩量 Diameter | 功率Power | 重量 weight | ||||
| 工作方式 | 繩數根 | 拉力 | 直徑 Duaneter | 快 | 慢 | ||||
| kg | mm | m | kw | kg | |||||
| JZ-10/600A | 纏繞式 | 1 | 10000 | 31 | 6 | 3 | 600 | 22 | 6160 |
| 2JZ-10/600A | 纏繞式 | 2 | 2×10000 | 31 | 6 | 3 | 600 | 40 | 11250 |
| JZ-16/800A | 纏繞式 | 1 | 16000 | 40.5 | 6 | 3 | 800 | 28 | 11500 |
| 2JZ-16/800A | 纏繞式 | 2 | 16000 | 40.5 | 6 | 3 | 800 | 55 | 21500 |
| JXM-25/800A | 磨擦式 | 1 | 25000 | 52 | 6 | 3 | 800 | 55 | 18650 |
| 2JZM-25/800A | 磨擦式 | 2 | 25000 | 52 | 3 | 800 | 75 | 37000 | |
| 2JZM-25/1350 | 磨擦式 | 2 | 25000 | 52 | 3 | 1350 | 75 | 39210 | |
| JZM-40/1350 | 磨擦式 | 1 | 40000 | 60.5 | 3 | 1350 | 80 | 37000 | |
