·MGC、YGC型固定車箱式窄軌礦車 Bottom type narrow

MGC、YGC型固定車箱式窄軌礦車 Bottom type narrow gauge mine car國家行業標準JB/T9027本礦車適用于煤礦、金屬礦山、地下巷道及地表工業場地運輸?shù)V石、廢石等其他物料?？蓲斐闪杏脵C(jī)車牽引、卸料用翻車機進行。Such mine cars are used in coal mines, metal mines, underworkings and operat

MGC、YGC型固定車箱式窄軌礦車 Bottom type narrow gauge mine car

國家行業標準JB/T9027

本礦車適用于煤礦、金屬礦山、地下巷道及地表工業場地運輸?shù)V石、廢石等其他物料。可掛成列用機車牽引、卸料用翻車機進行。

Such mine cars are used in coal mines, metal mines, underworkings and operation site to transport ores, barren rock, and other materials. They can be hung in rows and dragged by locomotives. Materials are unloaded through car dumpers.

型號規格Model	容積Volume	裝載量Loading weight	軌距Track base	牽引高度Dragging hight	牽引力Dragging force	外形尺寸 Overrall dimensions	質量Weigh t
型號規格Model	m³	t	mm	mm	KN	m	t
MGC0.5-6	0.5	1	600	320	60	1.3×0.8×1	0.34
MGC0.7-6	0.7	1.75	600	320	60	1.5×0.9×1.1	0.5
MGC1.1-6	1.1	1.8	600	320	60	2×0.9×1.2	0.58
MGC1.2-6	1.2	3	600	320	60	1.9×1.1×1.2	0.75
MGC1.2-7	1.2	3	762	320	60	1.9×1.1×1.2	0.8
MGC1.7-6	1.7	2.7	600	320	60	2.4×1×1.2	0.8
MGC1.7-9	1.7	2.7	900	320	60	2.4×1×1.2	0.9
MGC2-6	2	5	600	320	60	3×1.2×1.2	1.33
MGC2-7	2	5	762	320	60	3×1.2×1.2	1.35
MGC3.3-9	3.3	5.5	900	320	60	3.5×1.4×1.3	1.56
YGC0.5-6	0.5	1.25	600	320	60	2×0.9×1.2	0.61
YGC0.7-6	0.7	1.75	600	320	60	1.5×0.9×1.1	0.65
YGC1.2-6	1.2	3	600	320	60	1.9×1.1×1.2	0.72
YGC2-6	3	5	600	320	60	3×1.2×1.3	1.3
YGC4-7	4	10	762	320	60	3.7×1.3×1.6	1.62
YGC4-9	4	10	900	320	60	3.7×1.3×1.6	1.7
YGC10-7	10	25	762	430	79	7.2×1.5×1.6	7
YGC10-9	10	25	900	430	79	7.2×1.5×1.6	7.1
